Dynamode WL-GI-600XA Datasheet download pdf

WL-GI-600XA

INTRODUCTION

This highly efficient 54Mbps Wireless PCI Card is designed to meet the needs of those wireless

users who connect to 2.4GHz standard wireless networking devices. With the Dual-Standard capability,

this Wireless Network PCI automatically switches to the modulation methods i.e. OFDM, CCK and so on,

supported by one of the two standards, IEEE 802.11b or IEEE 802.11g, which the corresponding

wireless networking device is using. The WL-GI-600XA offers unbeatable performance of data rates up

to 54 Mbps for 802.11 g and 11 Mbps for 802.11b, while maintaining wide range of area coverage.

Wireless network security is protected with standard WEP encryption and Wi-Fi Protected Access

(WPA), and further enhanced with 802.1x authentication security. With drivers and utility available for

most commonly used Windows OS including Windows XP, the setup and installation can be easily

managed. Alternate external antenna kit model is also available combine with Soft AP utility developed

by GST to turn the Wireless PCI device into a fully operational Access Point. The WL-GI-600XA is a truly

solid-design networking device that provides you with the ultimate freedom of wireless networking –

anytime, anywhere.

54Mbps Wireless PCI Card

FEATURES

Fully IEEE 802.11g and 802.11b standards compliant.

Highly efficient design mechanism to provide unbeatable performance achieving data rate up to 54 Mbps for

802.11g and 11 Mbps for 802.11b with wide range coverage.

Strong network security with 802.1x, Wi-Fi Protected Access (WPA) and WEP encryption.

Auto-switch between the two standards IEEE 802.11b and g that the corresponding networking device is using.

Soft AP utility to provide full operational Access Point functionalities.

Driver/Utility supports most commonly used operating systems including Windows

98SE/ME/NT/2000/XP and Linux.

1 2

WL-GI-600XA 1
Dynamode 2

Summary of Contents

Page 1 - WL-GI-600XA

WL-GI-600XAINTRODUCTIONThis highly efficient 54Mbps Wireless PCI Card is designed to meet the needs of those wireless users who connect to 2.4GHz stan

Page 2 - Dynamode

PRODUCT SPECIFICATIONStandards· Wireless: IEEE 802.11b, 802.11g · PCI Standard v2.2Data Rate· 802.11g: Up to 54mbps (6/9/12/18/24/36/48/54)· 802.11b:
